Shipping begins in August 2020. Delivery schedules are subject to change. OLED 22 is a stunning new entry into the reference monitor space and SmallHD’s new standard for color perfectionists. Featuring a 1,000,000:1 contrast ratio with an absolute black point, and 100% P3 / 135% Rec 709 color gamuts that generate beautiful, true-to-life color accuracy. With the power of PageOS 4 histograms and waveforms, every tool is included to achieve perfection. OLED 22 prevents angle shift at any viewing position and provides a real-time image as vivid and pristine as the final output, on-set or in post.Product Highlights
21.6in/55cm OLED
3840×2160 Resolution
>1,000,000:1 Contrast
350nits
10-bit Color Depth
Weight: 9.35lbs / 4.2kg (with handle & feet)
Key Platform Highlights
PageOS 4 software platform
4K HDR waveform and scopes*
Dual & Quad-view*
Color Pipe HDR color rendering
Monitor Calibration Wizard
Small4K™ Video Processing Architecture
Inputs: 4x 12G-SDI , 1x HDMI 2.0
Outputs: 4x 12G-SDI, 1x HDMI 2.0*
Unibody Smart Chassis
Dovetail Mounting Rail for battery and accessory mounting
Interchangeable mounting points
2x 2-pin accessory power outputs
Power: Hot-swappable dual inputs: 1x 3-pin XLR, 1x Dual-GM/VM Battery Plate (sold separately)
Ships With Items
Basic Acrylic Screen Protector
3ft 4K HDMI Cable
2x 1/4-20 Cheese Stick Mounting Accessory
2x Combo Cheese Stick (1/4-20 + 3/8″)
Monitor Feet
Monitor Handle
3-pin XLR Power Supply
8GB SD Card
Microfiber Cleaning Cloth
*Update available Q4 2020 – (MON-OLED-22) – Sematron Italia official Teradek distributor – Sematron Italia distributore ufficiale Teradek
